Convert NMEA data from Elfin EW10 to Wi-Fi effortlessly
No problem! Let's break down how to turn your NMEA 0183 data into WiFi using the Elfin EW10, explore compatible devices and applications for real-time navigation, and more.
What's the Deal with NMEA 0183 and Going WiFi?
- NMEA 0183 is a classic data format used across marine electronics for communication between GPS receivers, chart plotters, AIS, autopilots, and the like.
- It's usually connected via serial communication (RS-232/RS-422), lacking the modern speed of WiFi.
- Transforming NMEA 0183 into WiFi lets you wirelessly stream nav data to smartphones, tablets, laptops, or other network-friendly devices for improved ease of use.
Elfin EW10 to the Rescue: Transforming NMEA 0183 to WiFi
Get to Know the Elfin EW10
- The Elfin EW10 is a marine data multiplexer and WiFi gateway made to convert serial NMEA 0183 data into a WiFi-friendly broadcast.
- It acts as a middleman, turning NMEA 0183 serial into a WiFi signal that smart apps or devices can munch on.
Let's Get Started
- Connect NMEA 0183 Source:
- Identify the device that sends NMEA 0183 data (e.g., GPS, AIS, autopilot).
- Connect TX and RX wires properly to the EW10's serial ports.
- Ensure sufficient voltage (usually +/- 12V or RS-232 levels) and stable power.
- Feed the EW10:
- Power the EW10 with 12V DC or per device instructions.
- Show the EW10 Some Love:
- Connect to the EW10's WiFi network (it often has its own SSID).
- Access its web interface via a browser (usually at an address like 192.168.4.1).
- Set parameters like baud rate (4800 or 38400 bps for NMEA 0183), sentence filtering, and WiFi credentials (if needed for your network).
- Connect Your Devices:
- Connect to the EW10 WiFi network on your phone, tablet, or laptop.
- Use compatible navigation apps to snag and interpret those NMEA sentences over WiFi.
Other Swell Devices for NMEA 0183 to WiFi Transformation
- Yacht Devices NMEA to WiFi Gateway: Decent NMEA 0183/2000-to-WiFi converter with broad app support.
- Actisense W2K-1 WiFi Gateway: Known for handling both NMEA 0183 and 2000, bridging to WiFi networks.
- Digital Yacht iKommunicate: A famed marine gateway device that transforms NMEA 0183/2000 to WiFi with custom support for proprietary protocols.
- Lantronix Serial-to-WiFi Converters: Adaptable serial-to-WiFi converters can be tweaked for NMEA 0183 streaming with personal settings.
Time to Navigate with Apps that Love Real-Time Navigation Data
Once you're enjoying WiFi NMEA 0183 data, many apps can chow down:
Mobile Marvels:
- Navionics Boating App: Works on smartphones and tablets, offering real-time charting and AIS overlay using NMEA WiFi inputs.
- iNavX (iOS/Android): Hot navigation app that accepts NMEA 0183 data over WiFi, plotting routes and waypoints, and offering real-time positioning.
- OpenCPN (Desktop/Mobile): Open-source navigation app that can cope with NMEA data streams.
- SailTimer (iOS/Android): Boasts live weather and navigation tools, all NMEA data compatible.
PC/Chartplotter Prowess:
- MaxSea TimeZero: robust marine navigation software that can absorb NMEA data streams over WiFi.
- NMEA Reader: Useful diagnostic tools that spew raw NMEA data for troubleshooting.
- Signalk Server: Open-source marine data server that's licensed to handle NMEA data streams and distribute them over networks.
Wrapping Up
| Step | What to Do | Additional Info ||-------------------|-------------------|-------------------|| Connect NMEA 0183 | Join TX/RX cables | Follow voltage || Power EW10 | Furnish 12V DC | Stable power || Set | Tweak WiFi Gateway | Access IP and || Parameters | settings | browser || Connect Client Devices| Join EW10 WiFi | Compatible apps |
Cruising Tips
- Safety first: double-check manual wiring and settings.
- Verify NMEA data flow through debugging tools before a full deployment.
- Conjoin multiple devices using a multi-sentence filter or multiplexer.
- Fortify your WiFi network to fend off opportunists.
