The AutomationDirect Titanio LW3A stepper drive, part of the Titanio series from Ever Motion Solutions, is a high-performance drive designed to control stepper motors efficiently in automation applications. This compact, reliable, and versatile drive offers several key features that make it an ideal choice for various industrial automation tasks.
Key Features of the Titanio LW3A Stepper Drive
The Titanio LW3A stepper drive is compatible with a wide range of stepper motors, particularly NEMA 23 and NEMA 34 sizes. It offers high-resolution microstepping with configurable step resolutions, enabling smooth and precise motor control. The drive supports current outputs of up to around 3A per phase, suitable for medium-power stepper motors, and operates within a voltage range of 20V to 50V DC, optimized for common industrial power supplies.
The drive accepts standard step and direction inputs, making it compatible with most motion controllers and PLCs. It includes built-in protections such as overcurrent, overvoltage, undervoltage, and thermal shutdown to enhance reliability and safety. The drive also provides DIP switches or potentiometers for easy setting of current limits and microstepping modes. Its compact design and mounting features for DIN rails or panels make it suitable for standard industrial control panels.
Diagnostic indicators such as LED indicators for status and fault conditions simplify troubleshooting and maintenance. Additionally, the Titanio LW3A stepper drive can detect stalls in open-loop control mode by monitoring the motor's back EMF, ensuring smooth and efficient operation.
Typical Specifications of the Titanio LW3A Stepper Drive
- Input Voltage: 20 to 50 VDC
- Output Current: Up to 3 A per phase
- Microstepping Resolution: Full step to 256 microsteps per step (configurable)
- Control Signals: Step and direction inputs (digital TTL compatible)
- Operating Temperature: Usually 0 to 50 °C ambient
- Dimensions: Compact form factor, often around a few inches in length and width (exact size depends on model specifics)
For exact and detailed technical data, configuration instructions, or compatibility queries, consulting the official datasheets and user manuals from Ever Motion Solutions or AutomationDirect is recommended.
Advanced Configuration with Ever Studio Software
The Titanio LW3A stepper drive can be configured using Ever Studio configuration software, which is available for free download. This software allows advanced configuration of the LW3A and LW4D stepper drives, providing users with the ability to customize the drive's settings to suit their specific application needs.
A Step Towards Efficiency: The Titanio Series
The Titanio series of stepper drives, including the LW3A model, provides increased, more consistent torque output at all speeds. These drives use sinusoidal current control for smooth motor movement, reducing audible noise, dampening vibration, and increasing system efficiency. The Titanio series is also compatible with AutomationDirect's SureStep stepper motors.
For those seeking a high-performance, reliable, and versatile stepper drive for their automation applications, the AutomationDirect Titanio LW3A stepper drive from Ever Motion Solutions is an excellent choice. Its key features, specifications, and compatibility with various motors make it an ideal solution for a wide range of industrial automation tasks.
